Bafang CAN-Protocol BBS02B 48V750W 52V1000W 68mm Mid Drive Motor DIY Ebike Conversion Kit W/ Battery With Display Optional

Product Description

MID-DRIVE SYSTEMS

HOW DO I KNOW IF THIS MID DRIVE MOTOR FITS FOR MY BIKE? 250W-750W: This mid drive motor fits for the bike with 68mm or 73mm wide bottom bracket. The inner diamater of the bracket should be not less than 33.5mm. 48V52V 1000W: The BBSHD comes in sizes made to fit the size of your bottom bracket. Please measure your bottom bracket before ordering, in case it does not fit. We have both in standard sizes (68-73mm), wide and fat sizes (74-100mm) and extra fat (100-120mm). If your bike is not regular, additional spacer may be needed : #68mm BBS: it's suitable for 68mm (2.68inch)-73mm (2.87inch) bike. #100mm BBS: 100mm bike or 90mm bike +1pc*10mm spacer #120mm BBS: 120mm bike or 110mm bike +1pc*10mm spacer

How to choose a display ? (UART/CAN-Protocol)

UART Display: 800S/850C/860C/750C/DP-C18
CAN Display: KD1286/ BAFANG C010/ C101 The main differences of the ebike displays are the interface , screen and holder size , specific function (check the display image below). If you want to quick decide which display should you choose, please check: NEW Arrivals :  C101 Popular Sale Displays :BAFANG C010 Display Cost Effective Displays : KD1286

How to choose a chainring for ebike conversion ？

For a normal pedal bike without electricity, small chainring is more compatible with mountain bike which can help you climb easier. Big chaining is more suitable for city bike, road bike and foldable bike which can help you enjoy faster speed . However , now you are converting a bike to an ebike with motor, the size of chainring won't influence much because there is enough power for you to ride. When you install a mid motor on your bike , the bigger the chainring is , the faster the speed wil be. And please note that the chainring is more compatible with a bike ≤9 speed. If you are not sure which chainring you should use, you can consider the same teeth as your original chainring.

Brake Lever or brake sensor ？

The brake lever we send by default has a power-off function. We provide you with some tips on choosing the appropriate braking system options. If your bicycle braking system is a mechanical disc brake or a wheel V-shaped brake, you can choose the brake lever option. If your bicycle braking system is an integrated thumb shifter, it is hydraulic braking, or if you want to keep your own brake lever. You can choose the brake sensor in the BAFANG mid wheel drive kit.

How to Choose the Right Battery

Motor-Optimized: Our batteries are designed to perfectly match our motors for peak performance.

Check Dimensions: Ensure compatibility with your bike:

48V 13AH: 113mm height (GC cells or S.amsung. cells )

48V 17.5AH 125mm(height (GC cells )

48V 20AH: 125mm height (GC cells or S.amsung. cells)

Premium Cells: High-quality GC or Samsung cells for durability and reliability.

Always verify battery dimensions before purchasing to ensure a proper fit for your bike.

Packing List 1 PC BAFANG Mid Drive Motor CAN Protocol 1 PC Display (Optional) 1 PC Chainwheel (Default 44T ) 1 Pair Brake Lever or 2PCS Brake Sensor (Optional) 1 Pair Crank 1 PC Thumb Throttle 1 PC Speed Sensor 1 PC 1T4 Cable 1 Set Accessories 1 PC Tool

1PC battery （According to your choice）
